APT64GA90LD30 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT 900V 117A 500W TO-264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT64GA90LD30 Specifications:
- MfrPart.: APT64GA90LD30
- Mfr: Microchip Technology
- Description: IGBT 900V 117A 500W TO-264
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 8™
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 900 V
- Current-Collector(Ic)(Max): 117 A
- Current-CollectorPulsed(Icm): 193 A
- Vce(on)(Max)@VgeIc: 3.1V @ 15V, 38A
- Power-Max: 500 W
- SwitchingEnergy: 1192µJ (on), 1088µJ (off)
- InputType: Standard
- GateCharge: 162 nC
- Td(on/off)@25°C: 18ns/131ns
- TestCondition: 600V, 38A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- APT64GA90LD30 Microchip, IGBT 900V 117A 500W TO-264, Discrete Semiconductor Products~Transistors - IGBTs - Single
