APT50MC120JCU2 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-227
- Description: MOSFET N-CH 1200V 71A SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT50MC120JCU2 Specifications:
- MfrPart.: APT50MC120JCU2
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1200V 71A SOT227
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 71A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 34mOhm @ 50A, 20V
- Vgs(th)(Max)@Id: 2.3V @ 1mA (Typ)
- GateCharge(Qg)(Max)@Vgs: 179 nC @ 20 V
- Vgs(Max): +25V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 2980 pF @ 1000 V
- FETFeature: -
- PowerDissipation(Max): 300W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SOT-227
- APT50MC120JCU2 Microchip, MOSFET N-CH 1200V 71A SOT227, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT50MC120JCU2, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
