APT50GT60BRG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 110A 446W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT50GT60BRG Specifications:
- MfrPart.: APT50GT60BRG
- Mfr: Microchip Technology
- Description: IGBT 600V 110A 446W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Thunderbolt IGBT®
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 110 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 50A
- Power-Max: 446 W
- SwitchingEnergy: 995µJ (on), 1070µJ (off)
- InputType: Standard
- GateCharge: 240 nC
- Td(on/off)@25°C: 14ns/240ns
- TestCondition: 400V, 50A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT50GT60BRG Microchip, IGBT 600V 110A 446W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT50GT60BRG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
