APT50GT120JU3 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: ISOTOP
- Description: IGBT MOD 1200V 75A 347W SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT50GT120JU3 Specifications:
- MfrPart.: APT50GT120JU3
- Mfr: Microchip Technology
- Description: IGBT MOD 1200V 75A 347W SOT227
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 75 A
- Power-Max: 347 W
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 50A
- Current-CollectorCutoff(Max): 5 mA
- InputCapacitance(Cies)@Vce: 3.6 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: ISOTOP
- APT50GT120JU3 Microchip, IGBT MOD 1200V 75A 347W SOT227, Discrete Semiconductor Products~Transistors - IGBTs - Modules
