APT50GS60BRDLG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 93A 415W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT50GS60BRDLG Specifications:
- MfrPart.: APT50GS60BRDLG
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT 600V 93A 415W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 93 A
- Current-CollectorPulsed(Icm): 195 A
- Vce(on)(Max)@VgeIc: 3.15V @ 15V, 50A
- Power-Max: 415 W
- SwitchingEnergy: 755µJ (off)
- InputType: Standard
- GateCharge: 235 nC
- Td(on/off)@25°C: 16ns/225ns
- TestCondition: 400V, 50A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT50GS60BRDLG Microchip, IGBT 600V 93A 415W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
