APT50GN120B2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 1200V 134A 543W TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT50GN120B2G Specifications:
- MfrPart.: APT50GN120B2G
- Mfr: Microchip Technology
- Description: IGBT 1200V 134A 543W TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT, Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 134 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 50A
- Power-Max: 543 W
- SwitchingEnergy: 4495µJ (off)
- InputType: Standard
- GateCharge: 315 nC
- Td(on/off)@25°C: 28ns/320ns
- TestCondition: 800V, 50A, 2.2Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- APT50GN120B2G Microchip, IGBT 1200V 134A 543W TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
