APT50GF120LRG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT 1200V 135A 781W TO264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT50GF120LRG Specifications:
- MfrPart.: APT50GF120LRG
- Mfr: Microchip Technology
- Description: IGBT 1200V 135A 781W TO264
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 135 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 3V @ 15V, 50A
- Power-Max: 781 W
- SwitchingEnergy: 3.6mJ (on), 2.64mJ (off)
- InputType: Standard
- GateCharge: 340 nC
- Td(on/off)@25°C: 25ns/260ns
- TestCondition: 800V, 50A, 1Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- APT50GF120LRG Microchip, IGBT 1200V 135A 781W TO264, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT50GF120LRG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
