APT50GF120JRDQ3 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: ISOTOP
- Description: IGBT MOD 1200V 120A 521W ISOTOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT50GF120JRDQ3 Specifications:
- MfrPart.: APT50GF120JRDQ3
- Mfr: Microchip Technology
- Description: IGBT MOD 1200V 120A 521W ISOTOP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 120 A
- Power-Max: 521 W
- Vce(on)(Max)@VgeIc: 3V @ 15V, 75A
- Current-CollectorCutoff(Max): 750 µA
- InputCapacitance(Cies)@Vce: 5.32 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: ISOTOP
- APT50GF120JRDQ3 Microchip, IGBT MOD 1200V 120A 521W ISOTOP, Discrete Semiconductor Products~Transistors - IGBTs - Modules
APT50GF120JRDQ3, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
