APT5024SLLG/TR Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3PAK
- Description: MOSFET N-CH 500V 22A D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT5024SLLG/TR Specifications:
- MfrPart.: APT5024SLLG/TR
- Mfr: Microchip Technology
- Description: MOSFET N-CH 500V 22A D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: POWER MOS 7®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 22A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 240mOhm @ 11A, 10V
- Vgs(th)(Max)@Id: 5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 43 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1900 pF/m @ 25 V
- FETFeature: -
- PowerDissipation(Max): 265W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D3PAK
- APT5024SLLG/TR Microchip, MOSFET N-CH 500V 22A D3PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT5024SLLG/TR, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
