APT5012JN Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: ISOTOP®
- Description: MOSFET N-CH 500V 43A ISOTOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT5012JN Specifications:
- MfrPart.: APT5012JN
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 500V 43A ISOTOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tray
- Series: POWER MOS IV®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 43A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 120mOhm @ 21.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: 370 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 6500 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 520W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: ISOTOP®
- APT5012JN Microchip, MOSFET N-CH 500V 43A ISOTOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
