APT5010B2LLG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: T-MAX™ [B2]
- Description: MOSFET N-CH 500V 46A T-MAX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT5010B2LLG Specifications:
- MfrPart.: APT5010B2LLG
- Mfr: Microchip Technology
- Description: MOSFET N-CH 500V 46A T-MAX
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 46A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 100mOhm @ 23A, 10V
- Vgs(th)(Max)@Id: 5V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: 95 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 4360 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 520W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: T-MAX™ [B2]
- APT5010B2LLG Microchip, MOSFET N-CH 500V 46A T-MAX, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
