APT4F120S Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3Pak
- Description: MOSFET N-CH 1200V 4A D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT4F120S Specifications:
- MfrPart.: APT4F120S
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1200V 4A D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: POWER MOS 8™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 4A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 4.2Ohm @ 2A, 10V
- Vgs(th)(Max)@Id: 5V @ 500µA
- GateCharge(Qg)(Max)@Vgs: 43 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1385 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 175W (Tc)
- OperatingTemperature: -
- MountingType: Surface Mount
- SupplierDevicePackage: D3Pak
- APT4F120S Microchip, MOSFET N-CH 1200V 4A D3PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT4F120S, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
