APT47N60SC3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3 [S]
- Description: MOSFET N-CH 600V 47A D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT47N60SC3G Specifications:
- MfrPart.: APT47N60SC3G
- Mfr: Microchip Technology
- Description: MOSFET N-CH 600V 47A D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: CoolMOS™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 47A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 70mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 3.9V @ 2.7mA
- GateCharge(Qg)(Max)@Vgs: 260 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 7015 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 417W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D3 [S]
- APT47N60SC3G Microchip, MOSFET N-CH 600V 47A D3PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
