APT45GR65B2DU30 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: INSULATED GATE BIPOLAR TRANSISTO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT45GR65B2DU30 Specifications:
- MfrPart.: APT45GR65B2DU30
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: INSULATED GATE BIPOLAR TRANSISTO
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 118 A
- Current-CollectorPulsed(Icm): 224 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 45A
- Power-Max: 543 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 203 nC
- Td(on/off)@25°C: 15ns/100ns
- TestCondition: 433V, 45A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): 80 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT45GR65B2DU30 Microchip, INSULATED GATE BIPOLAR TRANSISTO, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT45GR65B2DU30, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
