APT44GA60BD30C Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 78A 337W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT44GA60BD30C Specifications:
- MfrPart.: APT44GA60BD30C
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT 600V 78A 337W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 8™
- PartStatus: Obsolete
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 78 A
- Current-CollectorPulsed(Icm): 130 A
- Vce(on)(Max)@VgeIc: 1.6V @ 15V, 26A
- Power-Max: 337 W
- SwitchingEnergy: 409µJ (on), 450µJ (off)
- InputType: Standard
- GateCharge: 128 nC
- Td(on/off)@25°C: 16ns/102ns
- TestCondition: 400V, 26A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT44GA60BD30C Microchip, IGBT 600V 78A 337W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
