APT40GT60BRG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 80A 345W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT40GT60BRG Specifications:
- MfrPart.: APT40GT60BRG
- Mfr: Microchip Technology
- Description: IGBT 600V 80A 345W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Thunderbolt IGBT®
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 40A
- Power-Max: 345 W
- SwitchingEnergy: 828µJ (off)
- InputType: Standard
- GateCharge: 200 nC
- Td(on/off)@25°C: 12ns/124ns
- TestCondition: 400V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT40GT60BRG Microchip, IGBT 600V 80A 345W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT40GT60BRG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
