APT40GR120B2D30 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 88A 500W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT40GR120B2D30 Specifications:
- MfrPart.: APT40GR120B2D30
- Mfr: Microchip Technology
- Description: IGBT 1200V 88A 500W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 88 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 3.2V @ 15V, 40A
- Power-Max: 500 W
- SwitchingEnergy: 1.38mJ (on), 906µJ (off)
- InputType: Standard
- GateCharge: 210 nC
- Td(on/off)@25°C: 22ns/163ns
- TestCondition: 600V, 40A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT40GR120B2D30 Microchip, IGBT 1200V 88A 500W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
