APT40GP90B2DQ2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 900V 101A 543W TMAX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT40GP90B2DQ2G Specifications:
- MfrPart.: APT40GP90B2DQ2G
- Mfr: Microchip Technology
- Description: IGBT 900V 101A 543W TMAX
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 900 V
- Current-Collector(Ic)(Max): 101 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 3.9V @ 15V, 40A
- Power-Max: 543 W
- SwitchingEnergy: 795µJ (off)
- InputType: Standard
- GateCharge: 145 nC
- Td(on/off)@25°C: 14ns/90ns
- TestCondition: 600V, 40A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- APT40GP90B2DQ2G Microchip, IGBT 900V 101A 543W TMAX, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT40GP90B2DQ2G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
