APT40GP60SG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- Description: IGBT 600V 100A 543W D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT40GP60SG Specifications:
- MfrPart.: APT40GP60SG
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT 600V 100A 543W D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 40A
- Power-Max: 543 W
- SwitchingEnergy: 385µJ (on), 352µJ (off)
- InputType: Standard
- GateCharge: 135 nC
- Td(on/off)@25°C: 20ns/64ns
- TestCondition: 400V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- APT40GP60SG Microchip, IGBT 600V 100A 543W D3PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT40GP60SG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
