APT38N60SC6 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3Pak
- Description: MOSFET N-CH 600V 38A D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT38N60SC6 Specifications:
- MfrPart.: APT38N60SC6
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 600V 38A D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: CoolMOS™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 38A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 99mOhm @ 18A, 10V
- Vgs(th)(Max)@Id: 3.5V @ 1.2mA
- GateCharge(Qg)(Max)@Vgs: 112 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2826 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 278W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D3Pak
- APT38N60SC6 Microchip, MOSFET N-CH 600V 38A D3PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
