APT38F80B2 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: T-MAX™ [B2]
- Description: MOSFET N-CH 800V 41A T-MAX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT38F80B2 Specifications:
- MfrPart.: APT38F80B2
- Mfr: Microchip Technology
- Description: MOSFET N-CH 800V 41A T-MAX
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: POWER MOS 8™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 41A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 240mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 5V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: 260 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 8070 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1040W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: T-MAX™ [B2]
- APT38F80B2 Microchip, MOSFET N-CH 800V 41A T-MAX, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT38F80B2, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
