APT36N90BC3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247 [B]
- Description: MOSFET N-CH 900V 36A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT36N90BC3G Specifications:
- MfrPart.: APT36N90BC3G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 900V 36A TO247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: CoolMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 900 V
- Current-ContinuousDrain(Id)@25°C: 36A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 120mOhm @ 18A, 10V
- Vgs(th)(Max)@Id: 3.5V @ 2.9mA
- GateCharge(Qg)(Max)@Vgs: 252 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 7463 pF @ 25 V
- FETFeature: Super Junction
- PowerDissipation(Max): 390W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247 [B]
- APT36N90BC3G Microchip, MOSFET N-CH 900V 36A TO247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT36N90BC3G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
