APT36GA60SD15 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- Description: IGBT PT COMBI 600V 36A TO-268
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT36GA60SD15 Specifications:
- MfrPart.: APT36GA60SD15
- Mfr: Microchip Technology
- Description: IGBT PT COMBI 600V 36A TO-268
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 8®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 65 A
- Current-CollectorPulsed(Icm): 109 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 20A
- Power-Max: 290 W
- SwitchingEnergy: 307µJ (on), 254µJ (off)
- InputType: Standard
- GateCharge: 102 nC
- Td(on/off)@25°C: 16ns/122ns
- TestCondition: 400V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 19 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- APT36GA60SD15 Microchip, IGBT PT COMBI 600V 36A TO-268, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT36GA60SD15, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
