APT35GN120BG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 94A 379W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT35GN120BG Specifications:
- MfrPart.: APT35GN120BG
- Mfr: Microchip Technology
- Description: IGBT 1200V 94A 379W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT, Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 94 A
- Current-CollectorPulsed(Icm): 105 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 35A
- Power-Max: 379 W
- SwitchingEnergy: 2.315mJ (off)
- InputType: Standard
- GateCharge: 220 nC
- Td(on/off)@25°C: 24ns/300ns
- TestCondition: 800V, 35A, 2.2Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT35GN120BG Microchip, IGBT 1200V 94A 379W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
