APT30GS60BRDQ2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 54A 250W SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT30GS60BRDQ2G Specifications:
- MfrPart.: APT30GS60BRDQ2G
- Mfr: Microchip Technology
- Description: IGBT 600V 54A 250W SOT227
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Thunderbolt IGBT®
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 54 A
- Current-CollectorPulsed(Icm): 113 A
- Vce(on)(Max)@VgeIc: 3.15V @ 15V, 30A
- Power-Max: 250 W
- SwitchingEnergy: 570µJ (off)
- InputType: Standard
- GateCharge: 145 nC
- Td(on/off)@25°C: 16ns/360ns
- TestCondition: 400V, 30A, 9.1Ohm, 15V
- ReverseRecoveryTime(trr): 25 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT30GS60BRDQ2G Microchip, IGBT 600V 54A 250W SOT227, Discrete Semiconductor Products~Transistors - IGBTs - Single
