APT30GP60BG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 100A 463W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT30GP60BG Specifications:
- MfrPart.: APT30GP60BG
- Mfr: Microchip Technology
- Description: IGBT 600V 100A 463W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 100 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 30A
- Power-Max: 463 W
- SwitchingEnergy: 260µJ (on), 250µJ (off)
- InputType: Standard
- GateCharge: 90 nC
- Td(on/off)@25°C: 13ns/55ns
- TestCondition: 400V, 30A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT30GP60BG Microchip, IGBT 600V 100A 463W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
