APT25SM120S Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3
- Description: SICFET N-CH 1200V 25A D3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT25SM120S Specifications:
- MfrPart.: APT25SM120S
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: SICFET N-CH 1200V 25A D3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: SiCFET (Silicon Carbide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 25A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 175mOhm @ 10A, 20V
- Vgs(th)(Max)@Id: 2.5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 72 nC @ 20 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): 175W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: D3
- APT25SM120S Microchip, SICFET N-CH 1200V 25A D3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
