APT25GN120B2DQ2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 1200V 67A 272W TMAX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT25GN120B2DQ2G Specifications:
- MfrPart.: APT25GN120B2DQ2G
- Mfr: Microchip Technology
- Description: IGBT 1200V 67A 272W TMAX
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT, Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 67 A
- Current-CollectorPulsed(Icm): 75 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 25A
- Power-Max: 272 W
- SwitchingEnergy: 2.15µJ (off)
- InputType: Standard
- GateCharge: 155 nC
- Td(on/off)@25°C: 22ns/280ns
- TestCondition: 800V, 25A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- APT25GN120B2DQ2G Microchip, IGBT 1200V 67A 272W TMAX, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT25GN120B2DQ2G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
