APT24M80B Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247 [B]
- Description: MOSFET N-CH 800V 25A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT24M80B Specifications:
- MfrPart.: APT24M80B
- Mfr: Microchip Technology
- Description: MOSFET N-CH 800V 25A TO247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: POWER MOS 8™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 25A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 390mOhm @ 12A, 10V
- Vgs(th)(Max)@Id: 5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 150 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 4595 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 625W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247 [B]
- APT24M80B Microchip, MOSFET N-CH 800V 25A TO247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT24M80B, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
