APT23F60S Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3Pak
- Description: MOSFET N-CH 600V 24A D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT23F60S Specifications:
- MfrPart.: APT23F60S
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 600V 24A D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: POWER MOS 8™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 24A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 290mOhm @ 11A, 10V
- Vgs(th)(Max)@Id: 5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 110 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 4415 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 415W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D3Pak
- APT23F60S Microchip, MOSFET N-CH 600V 24A D3PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT23F60S, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
