APT20GN60BG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 40A 136W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT20GN60BG Specifications:
- MfrPart.: APT20GN60BG
- Mfr: Microchip Technology
- Description: IGBT 600V 40A 136W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 20A
- Power-Max: 136 W
- SwitchingEnergy: 230µJ (on), 580µJ (off)
- InputType: Standard
- GateCharge: 120 nC
- Td(on/off)@25°C: 9ns/140ns
- TestCondition: 400V, 20A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT20GN60BG Microchip, IGBT 600V 40A 136W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT20GN60BG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
