APT20GF120BRDG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT NPT COMBI 1200V 20A TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT20GF120BRDG Specifications:
- MfrPart.: APT20GF120BRDG
- Mfr: Microchip Technology
- Description: IGBT NPT COMBI 1200V 20A TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 32 A
- Current-CollectorPulsed(Icm): 64 A
- Vce(on)(Max)@VgeIc: 3.2V @ 15V, 15A
- Power-Max: 200 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 140 nC
- Td(on/off)@25°C: 17ns, 93ns
- TestCondition: 792V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 85 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT20GF120BRDG Microchip, IGBT NPT COMBI 1200V 20A TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT20GF120BRDG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
