APT18M100B Microchip MOSFET N-CH 1000V 18A TO247
APT18M100B Images
APT18M100B Images
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247 [B]
  • Description: MOSFET N-CH 1000V 18A TO247
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
APT18M100B Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
APT18M100B Specifications:
  • MfrPart.: APT18M100B
  • Mfr: Microchip Technology
  • Description: MOSFET N-CH 1000V 18A TO247
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 1000 V
  • Current-ContinuousDrain(Id)@25°C: 18A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 700mOhm @ 9A, 10V
  • Vgs(th)(Max)@Id: 5V @ 1mA
  • GateCharge(Qg)(Max)@Vgs: 150 nC @ 10 V
  • Vgs(Max): ±30V
  • InputCapacitance(Ciss)(Max)@Vds: 4845 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 625W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • SupplierDevicePackage: TO-247 [B]
  • APT18M100B Microchip, MOSFET N-CH 1000V 18A TO247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT18M100B, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
