APT15GP60BG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 56A 250W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT15GP60BG Specifications:
- MfrPart.: APT15GP60BG
- Mfr: Microchip Technology
- Description: IGBT 600V 56A 250W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 56 A
- Current-CollectorPulsed(Icm): 65 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 15A
- Power-Max: 250 W
- SwitchingEnergy: 130µJ (on), 121µJ (off)
- InputType: Standard
- GateCharge: 55 nC
- Td(on/off)@25°C: 8ns/29ns
- TestCondition: 400V, 15A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT15GP60BG Microchip, IGBT 600V 56A 250W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT15GP60BG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
