APT15GN120BDQ1G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 45A 195W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT15GN120BDQ1G Specifications:
- MfrPart.: APT15GN120BDQ1G
- Mfr: Microchip Technology
- Description: IGBT 1200V 45A 195W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 45 A
- Current-CollectorPulsed(Icm): 45 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 15A
- Power-Max: 195 W
- SwitchingEnergy: 410µJ (on), 950µJ (off)
- InputType: Standard
- GateCharge: 90 nC
- Td(on/off)@25°C: 10ns/150ns
- TestCondition: 800V, 15A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT15GN120BDQ1G Microchip, IGBT 1200V 45A 195W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
