APT150GN60B2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 600V 220A 536W SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT150GN60B2G Specifications:
- MfrPart.: APT150GN60B2G
- Mfr: Microchip Technology
- Description: IGBT 600V 220A 536W SOT227
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 220 A
- Current-CollectorPulsed(Icm): 450 A
- Vce(on)(Max)@VgeIc: 1.85V @ 15V, 150A
- Power-Max: 536 W
- SwitchingEnergy: 8.81mJ (on), 4.295mJ (off)
- InputType: Standard
- GateCharge: 970 nC
- Td(on/off)@25°C: 44ns/430ns
- TestCondition: 400V, 150A, 1Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- APT150GN60B2G Microchip, IGBT 600V 220A 536W SOT227, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT150GN60B2G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
