APT130SM70J Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-227 (ISOTOP®)
- Description: SICFET N-CH 700V 78A SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT130SM70J Specifications:
- MfrPart.: APT130SM70J
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: SICFET N-CH 700V 78A SOT227
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: SiCFET (Silicon Carbide)
- DraintoSourceVoltage(Vdss): 700 V
- Current-ContinuousDrain(Id)@25°C: 78A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 45mOhm @ 60A, 20V
- Vgs(th)(Max)@Id: 2.4V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 270 nC @ 20 V
- Vgs(Max): +25V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 3950 pF @ 700 V
- FETFeature: -
- PowerDissipation(Max): 273W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SOT-227 (ISOTOP®)
- APT130SM70J Microchip, SICFET N-CH 700V 78A SOT227, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
