APT12060LVRG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-264 (L)
- Description: MOSFET N-CH 1200V 20A TO264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT12060LVRG Specifications:
- MfrPart.: APT12060LVRG
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1200V 20A TO264
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: POWER MOS V®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 20A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 600mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 4V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: 650 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 9500 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 625W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-264 (L)
- APT12060LVRG Microchip, MOSFET N-CH 1200V 20A TO264, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
