APT100S20BG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-247-2
- Description: DIODE SCHOTTKY 200V 120A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT100S20BG Specifications:
- Manufacturer Product Number: APT100S20BG
- Mfr: Microchip Technology
- Detailed Description: DIODE SCHOTTKY 200V 120A TO247
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tube
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 200 V
- Current - Average Rectified (Io): 120A
- Voltage - Forward (Vf) (Max) @ If: 950 mV @ 100 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 70 ns
- Current - Reverse Leakage @ Vr: 2 mA @ 200 V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-247-2
- Operating Temperature - Junction: -55°C ~ 150°C
- APT100S20BG Microchip, DIODE SCHOTTKY 200V 120A TO247, Discrete Semiconductor Products~Diodes - Rectifiers - Single
APT100S20BG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
