APT100GT60JR Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: ISOTOP
- Description: IGBT MOD 600V 148A 500W ISOTOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT100GT60JR Specifications:
- MfrPart.: APT100GT60JR
- Mfr: Microchip Technology
- Description: IGBT MOD 600V 148A 500W ISOTOP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tube
- Series: Thunderbolt IGBT®
- PartStatus: Active
- IGBTType: NPT
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 148 A
- Power-Max: 500 W
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 100A
- Current-CollectorCutoff(Max): 25 µA
- InputCapacitance(Cies)@Vce: 5.15 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: ISOTOP
- APT100GT60JR Microchip, IGBT MOD 600V 148A 500W ISOTOP, Discrete Semiconductor Products~Transistors - IGBTs - Modules
