APT100GN60B2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 600V 229A 625W TMAX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT100GN60B2G Specifications:
- MfrPart.: APT100GN60B2G
- Mfr: Microchip Technology
- Description: IGBT 600V 229A 625W TMAX
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 229 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 1.85V @ 15V, 100A
- Power-Max: 625 W
- SwitchingEnergy: 4.7mJ (on), 2.675mJ (off)
- InputType: Standard
- GateCharge: 600 nC
- Td(on/off)@25°C: 31ns/310ns
- TestCondition: 400V, 100A, 1Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- APT100GN60B2G Microchip, IGBT 600V 229A 625W TMAX, Discrete Semiconductor Products~Transistors - IGBTs - Single
