APT1003RSFLLG/TR Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3PAK
- Description: MOSFET N-CH 1KV 4A D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT1003RSFLLG/TR Specifications:
- MfrPart.: APT1003RSFLLG/TR
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1KV 4A D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: POWER MOS 7®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1 kV
- Current-ContinuousDrain(Id)@25°C: 4A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 3Ohm @ 2A, 10V
- Vgs(th)(Max)@Id: 5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 34 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 694 pF/m @ 25 V
- FETFeature: -
- PowerDissipation(Max): 139W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D3PAK
- APT1003RSFLLG/TR Microchip, MOSFET N-CH 1KV 4A D3PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
