APL502B2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: T-MAX™ [B2]
- Description: MOSFET N-CH 500V 58A T-MAX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APL502B2G Specifications:
- MfrPart.: APL502B2G
- Mfr: Microchip Technology
- Description: MOSFET N-CH 500V 58A T-MAX
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 58A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 15V
- RdsOn(Max)@IdVgs: 90mOhm @ 29A, 12V
- Vgs(th)(Max)@Id: 4V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 9000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 730W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: T-MAX™ [B2]
- APL502B2G Microchip, MOSFET N-CH 500V 58A T-MAX, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APL502B2G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
