APL1001J Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: ISOTOP®
- Description: MOSFET N-CH 1000V 18A ISOTOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APL1001J Specifications:
- MfrPart.: APL1001J
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1000V 18A ISOTOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1000 V
- Current-ContinuousDrain(Id)@25°C: 18A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 600mOhm @ 500mA, 10V
- Vgs(th)(Max)@Id: 4V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 7200 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 520W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: ISOTOP®
- APL1001J Microchip, MOSFET N-CH 1000V 18A ISOTOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APL1001J, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
