2N6762 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-204AA
- Description: MOSFET N-CH 500V 4.5A TO204AA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N6762 Specifications:
- MfrPart.: 2N6762
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 500V 4.5A TO204AA
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 4.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.8Ohm @ 4.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): 4W (Ta), 75W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-204AA
- 2N6762 Microchip, MOSFET N-CH 500V 4.5A TO204AA, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
2N6762, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
