2N5114 Microchip P CHANNEL JFET
2N5114 Images
2N5114 Images
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Transistors - JFETs Package/Case: TO-206AA, TO-18-3 Metal Can
  • Description: P CHANNEL JFET
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
2N5114 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
2N5114 Specifications:
  • MfrPart.: 2N5114
  • Mfr: Microchip Technology
  • Description: P CHANNEL JFET
  • Product Category: Discrete Semiconductor Products~Transistors - JFETs
  • Package: Bulk
  • Series: Military, MIL-PRF-19500
  • PartStatus: Active
  • FETType: P-Channel
  • Voltage-Breakdown(V(BR)GSS): 30 V
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-Drain(Idss)@Vds(Vgs=0): 90 mA @ 18 V
  • CurrentDrain(Id)-Max: -
  • Voltage-Cutoff(VGSoff)@Id: 10 V @ 1 nA
  • InputCapacitance(Ciss)(Max)@Vds: 25pF @ 15V
  • Resistance-RDS(On): 75 Ohms
  • Power-Max: 500 mW
  • OperatingTemperature: -65°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-206AA, TO-18-3 Metal Can
  • 2N5114 Microchip, P CHANNEL JFET, Discrete Semiconductor Products~Transistors - JFETs
2N5114, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
