2N5014S Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-205AD, TO-39-3 Metal Can
- Description: TRANSISTOR NPN TO-39
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N5014S Specifications:
- MfrPart.: 2N5014S
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: TRANSISTOR NPN TO-39
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/727
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 200 mA
- Voltage-CollectorEmitterBreakdown(Max): 900 V
- VceSaturation(Max)@IbIc: 1.6V @ 5mA, 20mA
- Current-CollectorCutoff(Max): 10nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 30 @ 20mA, 10V
- Power-Max: 1 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-205AD, TO-39-3 Metal Can
- 2N5014S Microchip, TRANSISTOR NPN TO-39, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2N5014S, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
