2N4029 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-206AA, TO-18-3 Metal Can
- Description: TRANS PNP 80V 1A TO-18
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N4029 Specifications:
- MfrPart.: 2N4029
- Mfr: Microchip Technology
- Description: TRANS PNP 80V 1A TO-18
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- TransistorType: PNP
- Current-Collector(Ic)(Max): 1 A
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 1V @ 100mA, 1A
- Current-CollectorCutoff(Max): 10µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 100mA, 5V
- Power-Max: 500 mW
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-206AA, TO-18-3 Metal Can
- 2N4029 Microchip, TRANS PNP 80V 1A TO-18, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2N4029, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
