2N3822 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - JFETs Package/Case: TO-206AF, TO-72-4 Metal Can
- Description: N CHANNEL JFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N3822 Specifications:
- MfrPart.: 2N3822
- Mfr: Microchip Technology
- Description: N CHANNEL JFET
- Product Category: Discrete Semiconductor Products~Transistors - JFETs
- Package: Bulk
- Series: Military, MIL-PRF-19500/375
- PartStatus: Discontinued at
- FETType: N-Channel
- Voltage-Breakdown(V(BR)GSS): 50 V
- DraintoSourceVoltage(Vdss): 50 V
- Current-Drain(Idss)@Vds(Vgs=0): 10 mA @ 15 V
- CurrentDrain(Id)-Max: -
- Voltage-Cutoff(VGSoff)@Id: 6 V @ 500 pA
- InputCapacitance(Ciss)(Max)@Vds: 6pF @ 15V
- Resistance-RDS(On): -
- Power-Max: 300 mW
- OperatingTemperature: -55°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-206AF, TO-72-4 Metal Can
- 2N3822 Microchip, N CHANNEL JFET, Discrete Semiconductor Products~Transistors - JFETs
2N3822, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
