2N3811 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: TO-78-6 Metal Can
- Description: TRANS 2PNP 60V 0.05A TO-78
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N3811 Specifications:
- MfrPart.: 2N3811
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: TRANS 2PNP 60V 0.05A TO-78
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: 2 PNP (Dual)
- Current-Collector(Ic)(Max): 50mA
- Voltage-CollectorEmitterBreakdown(Max): 60V
- VceSaturation(Max)@IbIc: 250mV @ 100µA, 1mA
- Current-CollectorCutoff(Max): 10µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 300 @ 1mA, 5V
- Power-Max: 350mW
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-78-6 Metal Can
- 2N3811 Microchip, TRANS 2PNP 60V 0.05A TO-78, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
